pcolor and contour plot with different colormaps

pospiech — Sun, 11 Mar 2012 18:25:18 +0000

Matlab does not allow to combine use more than one colormap in a figure. However there are some possibilities to get around this problem, which are presented in this article.

Initilisation and export of figure

For all plots the same initialisation for the data and the figure is used:

% clear command window, figures and all variables
clc; clf; clear all;

%% Common variables

FontSize = 12;
FontName = 'MyriadPro-Regular'; % or choose any other font

doExportPlot = true;

%% Plot variables
SaveDir = '';

TITLE = '';
    xLabelText = 'x-values';
    yLabelText = 'y-values';
    zLabelText = 'function values';


%%
SaveDir = '';
BaseDir = '';
%% Create Data
[x y data] = peaks(1000);
data = data - min(min(data));
data = data / max(max(data));

%% start plot

% figure dimensions in cm. I choose 1.5 or 2 times
% the target size typically. If figure is display in
% document much smaller increase the fontsize.

figure_width = 14;
figure_height = 10;

% --- setup plot windows
figuresVisible = 'on'; % 'off' for non displayed plots (will still be exported)
hfig = figure(1); clf;
    set(hfig,'Visible', figuresVisible)

    set(hfig, 'units', 'centimeters', 'pos', [5 5 figure_width figure_height])
    set(hfig, 'PaperPositionMode', 'auto');
    set(hfig, 'Renderer','zbuffer');
    set(hfig, 'Color', [1 1 1]); % Sets figure background
    set(gca, 'Color', [1 1 1]); % Sets axes background

% --- dimensions and position of plot
hsp = subplot(1,1,1, 'Parent', hfig);
set(hsp,'Position',[0.12 0.15 0.80 0.8]);

colorDepth = 1000;

And the same code is used to style the plot and export the figure:

%%  setup axis plot properties
% shading interp; % interpolate pixels
axis on;      % display axis
axis tight;   % no white borders

set(gca, ...
    'Box'         , 'on'      , ...
    'TickDir'     , 'in'      , ...
    'TickLength'  , [.02 .02] , ...
    'XMinorTick'  , 'off'      , ...
    'YMinorTick'  , 'off'     , ...
    'XGrid'       , 'off'     , ...
    'YGrid'       , 'off'     , ...
    'XColor'      , [.0 .0 .0], ...
    'YColor'      , [.0 .0 .0], ...
    'LineWidth'   , 0.6        );

%% axis scales

% set(gca,'XTick',-15:5:15)
% set(gca,'YTick',-10:5:10)

%% label texts

% save handles to set up label properties
hTitle = title(TITLE);
hXLabel = xlabel(xLabelText);
hYLabel = ylabel(yLabelText);

%% set properties for all handles
set([gca, hTitle, hXLabel, hYLabel], ...
    'FontSize'   , FontSize    , ...
    'FontName'   , FontName);


%% last 'bug' fixes

% bring axis on top again (fix matlab bug)
set(gca,'Layer', 'top');

%% export
drawnow

doExportPlot = true;
if (doExportPlot)
    IMAGENAME = [SaveDir SaveName];
    print(hfig, ['-r' num2str(400)], [IMAGENAME '.png' ], ['-d' 'png']);
end

Next page: “contour with white lines”

plotyy with unequal tick locations for both datasets

pospiech — Sun, 12 Feb 2012 22:08:08 +0000

In matlab the normal way to create plots with two y-axis is to use the command plotyy.

This works quite simple, and creates equal tick locations for both data sets:

xaxis = 0:0.1:25;
y1 = linspace(12.1712,12.7679, length(xaxis));
y2 = linspace(0.3597,-28.7745, length(xaxis));

[AX,H1,H2] = plotyy(xaxis, y1, xaxis, y2);

plotstyle; % sets only colors, linestyle and fonts

However for tick that are not equal on both sides the plot looks simply wrong.

[AX,H1,H2] = plotyy(xaxis, y1, xaxis, y2);

% axis limits - x axis (min to max)
set(AX, 'XLim', [min(xaxis) max(xaxis)]);
set(AX(2),'XTick',[]);

% y1 axis limits
set(AX(1), 'YLim', [min(y1) max(y1)]);

% y2 axis limits
set(AX(2), 'YLim', [min(y2) max(y2)]);

plotstyle;

Unfortunately the web is full of question on how to remove the ticks on the opposite side. But Matlab completely fails at this point. It is simply not supported properly.

The only solution I could find/retrieve in a forum was the following one, which is based on the idea to remove the box property which paints the ticks on the opposite side. But it also removes the surrounding box, which is unwanted.

set(AX(1),'Box','off') % Turn off box of axis 1, which removes its right-hand ticks
set(AX(2),'Box','off') % Turn off box of axis 2, which removes its left-hand ticks

Another idea I found in this thread is to work with dummy axes, but I do not see how to integrate it with my plot function (the plot is empy after I execute this code)

% dummy axes for the box and background color
ax0 = axes;
set (ax0, 'Box', 'on', 'Color', 'white', 'XTick', [], 'YTick', []);
% first axes for left y-axis
ax1 = axes ('Position', get (ax0, 'Position'));
set (ax1, 'Box', 'off', 'Color', 'none', 'YAxisLocation', 'left');
% second axes for right y-axis assuming common x-axis controlled by ax1
ax2 = axes ('Position', get (ax0, 'Position'));
set (ax2, 'Box', 'off', 'Color', 'none', 'XTick', [], 'YAxisLocation', 'right');

Any hints or other solutions are welcome. please use this thread on stackoverflow.com for adding answers on your own.
